The center is equipped with a Quantum Design PPMS DynaCool system, enabling the following measurements:
- Thermal transport
- Heat capacity
- Electrical transport
- DC resistivity
The Dynacool has a 14T magnet, and a temperature range of 1.85K to 400K.
For booking please use bookme (under “Schedule” choose “bookings”, scroll up and change from “Central Library” to “QMR Center” with the small arrow next to the header, then choose the equipment and slot), or contact us directly (via email).
All financial questions should be addressed to Israel Ben Efraim (firstname.lastname@example.org)
Also please see calendar for availability.
A customer within the Technion will pay NIS 100 per work hour.
Out of Technion customers will pay NIS 150 per work hour plus VAT.
The DC resistivity option sample holder can accommodate a sample of size: ~1cm by ~1.5cm. It has 3 four-probe options for connection and needs to be wire-bonded prior to measurement.
The power range for resistivity measurements is 1nW-1mW, 10nA-5mA in current and 1mV-95mV voltage.
The sample holder is electrically conductive, therefore an insulating and thermally conducting layer needs to be placed between the sample and holder.
